ActiveAid SC Rolling Shower & Commode Chair

Request a Quote



The ActiveAid SC is a self-propelled shower commode chair that redefines the aesthetic of traditional chairs. The frame design represents far more than looks; it results in one of the market’s most narrow, compact, and modular systems. It enables access to small bathrooms and doorways with new slim wheels and hand rims. The modular design allows the frame, wheels, and positioning options to adapt to individual needs.

A wide range of standard features and options creates a system that enables clients and clinicians to determine priorities and consider environmental factors, then truly tailor the configuration to meet client needs without custom modifications. The frame has two height-adjustable size options (Standard and Short), which expands the seat-to-floor range and enables tailored bathroom/shower solutions. Additional features such as independent, adjustable seat slope, fore-aft seat aperture adjustment capability, back angle adjustment, and frame adjustments like rear wheel position represent user-focused design and a level of customization akin to lightweight manual wheelchairs rather than shower commode chairs.

  • The ActiveAid SC introduces an exciting upgrade to the standard shower/commode chair with five distinct color options. Red, White, Blue, Black, and Silver.
  • The ActiveAid SC comes in 3 seat sizes: 16”, 18”, 20” widths
  • The ActiveAid SC features five ergonomic and comfortable seat shape options. These versatile designs enhance perineal access, providing improved hygiene benefits.
  • The ActiveAid SC stands out as one of the market’s most narrow, compact, and modular shower/commode chairs. Featuring a unique array of adjustable options, it empowers you to fully customize the SC to suit your specific needs. These include an adjustable back, adjustable arms, seat aperture, and adjustable seat slope.
  • The ActiveAid SC boasts a narrow and compact frame allowing for improved turning radius.
  • The ActiveAid SC has multiple foot plate shapes and adjustability options, giving you the power to customize your ActiveAid SC to suit your bathroom and transfer needs.

The ActiveAid SC is a self-propelled shower commode chair that redefines the aesthetic of traditional chairs. The frame design represents far more than looks; it results in one of the market’s most narrow, compact, and modular systems. It enables access to small bathrooms and doorways with new slim wheels and hand rims. The modular design allows the frame, wheels, and positioning options to adapt to individual needs.

A wide range of standard features and options creates a system that enables clients and clinicians to determine priorities and consider environmental factors, then truly tailor the configuration to meet client needs without custom modifications. The frame has two height-adjustable size options (Standard and Short), which expands the seat-to-floor range and enables tailored bathroom/shower solutions. Additional features such as independent, adjustable seat slope, fore-aft seat aperture adjustment capability, back angle adjustment, and frame adjustments like rear wheel position represent user-focused design and a level of customization akin to lightweight manual wheelchairs rather than shower commode chairs.

  • The ActiveAid SC introduces an exciting upgrade to the standard shower/commode chair with five distinct color options. Red, White, Blue, Black, and Silver.
  • The ActiveAid SC comes in 3 seat sizes: 16”, 18”, 20” widths
  • The ActiveAid SC features five ergonomic and comfortable seat shape options. These versatile designs enhance perineal access, providing improved hygiene benefits.
  • The ActiveAid SC stands out as one of the market’s most narrow, compact, and modular shower/commode chairs. Featuring a unique array of adjustable options, it empowers you to fully customize the SC to suit your specific needs. These include an adjustable back, adjustable arms, seat aperture, and adjustable seat slope.
  • The ActiveAid SC boasts a narrow and compact frame allowing for improved turning radius.
  • The ActiveAid SC has multiple foot plate shapes and adjustability options, giving you the power to customize your ActiveAid SC to suit your bathroom and transfer needs.
Features

Rolling

Size

Standard

Padded

Yes

Specifications





Description 16″ Wide Seat 18″ Wide Seat 20″ Wide Seat
Weight limit 310 lbs. 310 lbs. 310 lbs.
Weight of basic unit 49 lbs. 49 lbs. 49 lbs.
Overall width (including hand rims) 23.5″ 25.5″ 27.5″
Width between arm rests 16.25″ 18.25″ 20.25″
Under seat width clearance at axle 12.625″ 14.625″ 16.625″
Under seat width clearance at axle plate 14.125″ 16.125″ 18.125″
Under seat height clearance (short front
tubes/axle plates, O” dump)
17″-18.75″ 17″-
18.75″
17″-
18.75″
Under seat height clearance (long front
tubes/axle plates, O” dump)
19″ – 20.75″ 19″ –
20.75″
19″ –
20.75″
Wheel diameters 20″, 22″, 24″ 20″, 22″,
24″
20″, 22″,
24″
Minimum depth without footrests (20″
wheels)
27.5″ 29.5″ 31.5″
Minimum depth without footrests (22″
wheels)
28.5″ 30.5″ 32.5″
Minimum depth without footrests (24″
wheels)
29.5″ 31.5″ 33.5″
Maximum depth without footrests (20″
wheels)
30.25″ 32.25″ 34.25″
Maximum depth without footrests (22″
wheels)
31.25″ 33.25″ 35.25″
Maximum depth without footrests (24″
wheels)
32.25″ 34.25″ 36.25″
Maximum dimensions 23.5″ X 32.25″ X
42″
25.5″ X
34.25″ X
42″
27.5″ X
36.25″ X
42″
Footplate dimensions (single piece
fixed/adjustable)
9.5″ X 8.438″ 11.5″ X
8.438″
13.s”x
8.438″
Footplate dimensions (gooseneck) 5.875″ X 8.438″
6.875″ X 8.438″
7.875″ X 8.438″
5.875″ X
8.438″
6.875″ X
8.438″
7.875″ X
8.438″
5.875″ X
8.438″
6.875″ X
8.438″
7.875″ X
8.438″
Footplate dimensions (flip-up) 4.25″ X 8.438″
5.25″ X 8.438″
6.25″ X 8.438″
4.25″ X
8.438″
5.25″ X
8.438″
6.25″ X
8.438″
4.25″ X
8.438″
5.25″ X
8.438″
6.25″ X
8.438″
Lateral support pad size 5″ X 3″ X 1″ 5″ X 3″ X 1″ 5″ X 3″ X 1″
Lateral support adjustment range O” -16″ O” -16″ O” – 16″
Seat height range from floor to top of seat 20″-
23.75″
20″ –
23.75″
20″ –
23.75″
Maximum seat dump 1.5″ 1.5″ 1.5″
Seat fore/aft adjustment 2″ 2″ 2″
Axle fore/aft adjustment 2.75″ 2.75″ 2.75″
Back of unit to start of the commode
opening (20″ wheels, seat all the way back)
12.75″ 12.75″ 12.75″
Back of unit to start of the commode
opening (22″ wheels, seat all the way back)
13.75″ 13.75″ 13.75″
Back of unit to start of the commode
opening (24″ wheels, seat all the way back)
14.75″ 14.75″ 14.75″
Turning diameter 22″ 23.5″ 25″
Armrest height from top of seat 5.5″ -12″ 5.5″ – 12″ 5.5″ – 12″
Leg rest range (single piece
fixed/adjustable, short front tubes)
15.75″ -17.75″ 15.75″ –
17.75″
15.75″ –
17.75″
Leg rest range (single piece
fixed/adjustable, long front tubes)
17.75″ -19.75″ 17.75″ –
19.75″
17.75″ –
19.75″
Leg rest range (gooseneck, short front
tubes)
15″ – 23″ 15″ – 23″ 15″ – 23″
Leg rest range (gooseneck, long front tubes) 15″ – 25″ 15″ -25″ 15″ – 25″
Leg rest range (flip-up, short front tubes) 15.5″ -17.5″ 15.5″ –
17.5″
15.5″ –
17.5″
Leg rest range (flip-up, long front tubes) 17.5″ -19.5″ 17.5″ –
19.5″
17.5″ –
19.5″
Back height from top of seat (O” dump) 7.75″ -16″ 7.75″ -16″ 7.75″ -16″
Gap between top of seat and bottom of
back (O” dump)
O” -8.25″ O” -8.25″ O” -8.25″
Back angles with angle-adjustable back 0°, 7°, 14° 0°, 7°, 14° 0°, 7°, 14°
Back angle with fixed back
Under seat height clearance (short front tubes/axle plates, without commode pan,
O” dump)
17″-18.75″ 17″-
18.75″
17″-
18.75″
Under seat height clearance (long front tubes/axle plates, without commode pan, O” dump) 19″ – 20.75″ 19″ –
20.75″
19″ –
20.75″
Under seat height clearance (short front
tubes, 011 dumo, flush mount)
10.25″ -14″ 10.25″ –
14″
10.25″ –
14″
Under seat height clearance (long front
tubes, O” dump, flush mount)
12.25″ -16″ 12.25″ –
16″
12.25″ –
16″
