Drive Full-Electric Low Height Bed
$1,444.50
The Drive Full-Electric Low Height Bed offers the safety and convenience of a low bed, which are often used when injuries from falling out of bed are a concern. Featuring height adjustment and head and foot deck motors which come pre-installed on the foot section (no assembly required). It also the flexibility to configure “roll at any height” or “roll at low height only” castor location.
The quiet, convenient, full electric operation provides smooth position change with an easy-to-use Hand Pendant control of Head/Foot Section positioning and overall height of the bed frame for maximum comfort and versatility for the patient or caregiver. In the event of power failure, top-mounted crank accessibility and manual crank motor override of sleep surface adjustments.
The Full-Electric Low Height Bed has channel frame construction which provides superior strength and reduced weight. The reinforced frame also resists twisting and bending and has long-lasting Zinc-coated spring deck for occupant comfort. Its heavy-duty bed ends with durable HD Polyethylene Molded Bed End covers are attractive, easy-to-maintain.
The ergonomic hand pendant comes with durable strain relief and a heavy-duty cord with a waterproof casing for easy cleaning.
Patient Weight Capacity 350 lbs. Total Weight Capacity 450 lbs. – includes occupant, mattress, rails, trapeze, accessories, personal effects, etc.
The Drive Full-Electric Low Height Bed offers the safety and convenience of a low bed, which are often used when injuries from falling out of bed are a concern. Featuring height adjustment and head and foot deck motors which come pre-installed on the foot section (no assembly required). It also the flexibility to configure “roll at any height” or “roll at low height only” castor location.
The quiet, convenient, full electric operation provides smooth position change with an easy-to-use Hand Pendant control of Head/Foot Section positioning and overall height of the bed frame for maximum comfort and versatility for the patient or caregiver. In the event of power failure, top-mounted crank accessibility and manual crank motor override of sleep surface adjustments.
The Full-Electric Low Height Bed has channel frame construction which provides superior strength and reduced weight. The reinforced frame also resists twisting and bending and has long-lasting Zinc-coated spring deck for occupant comfort. Its heavy-duty bed ends with durable HD Polyethylene Molded Bed End covers are attractive, easy-to-maintain.
The ergonomic hand pendant comes with durable strain relief and heavy-duty cord with waterproof casing for easy cleaning.
Patient Weight Capacity 350 lbs. Total Weight Capacity 450 lbs. – includes occupant, mattress, rails, trapeze, accessories, personal affects, etc.
- Low Deck height with flexibility to configure “roll at any height” or “roll at low height only” castor location
- -Roll at any Height: 14.81″ (376mm) to 22.83″ (580 mm) deck height
- -Roll at Low Height: 11.81 (300 mm) to 19.83″ (504mm) deck height
- Quiet, convenient, full electric operation provides smooth position change w/easy-to-use Hand Pendant control of Head/Foot Section positioning and overall height of the bed frame for maximum comfort and versatility for the patient or caregiver
- Height-adjustment and Head/Foot deck motors
- In the event of power failure, top mounted Hi/Lo crank accessibility and manual crank motor override of sleep surface adjustments
- Easy-to-transport and set up
- Channel frame construction provides superior strength and reduced weight
- Reinforced frame resists twisting and bending
- Long lasting Zinc-coated spring deck for Patient comfort
- Heavy-duty bed ends with durable HD Polyethylene Molded Bed End covers are attractive, easy-to-maintain
- Headboard is taller than foot-board to blend with home décor
- Labels and color-coded springs help ensure the accurate installation of side rails for patient safety
- High-performance 3-motor power plant is an industry-standard
- The motor is UL Approved, Bed is manufactured in ISO9001 & ISO13485 facility
- Satisfies applicable FDA entrapment guidelines
- Patient Weight Capacity 350 lbs. Total Weight Capacity 450 lbs.- includes occupant, mattress, rails, trapeze, accessories, personal effects, etc.
Configuration options
- Gravity Foam mattress with or without bolsters
- Low Air Loss Alternating Pressure Mattress System
- Half length Bed Rails
BT ID: 15005LPpital bed
| Weight | 404 lbs |
|---|---|
| Weight Capacity | 350 lbs |
| User Weight | Less than 250 lbs., 251 – 300 lbs., 301-350 lbs. |
| Mattresses Homecare | Gravity 7 Memory Foam (+$240.75), Gravity 7 Memory Foam (+$241), Gravity 7 Memory Foam Bolstered (+$294.25), Gravity 7 Memory Foam Bolstered (+$295), No Mattress (+$0) |
| Bed Rails Homecare | Half-Rails (+$160.50), Half-Rails (+$161), No Rails (+$0) |
Specifications
| Overall Length | 87.99″ |
| Overall Width w/o Rails | 36.22″ |
| Overall Width w/Rails | 38.58″ |
| Length & Width of Mattress Deck | 79.53″ x 34.65″ |
| Height Range | 11.81″ – 22.83″ |
| Maximum Weight Capacity | 350 lbs Patient Wgt / 450 lbs includes all accessories |
| Under Bed Clearance | 2.6″ |
| Total Product Weight | 169 lbs. |
| Head End & Head Section | 68 lbs. |
| Foot End & Foot Section | 101 lbs. |
| Warranty | Original Purchaser. Limited Lifetime on welds, 5 year on frame, motor, pendant, 1 year on all other parts and components. During the warranty period, defective items will be repaired or replaced at Drive’s option at no charge |
Mattress Options
Low Air Loss Alternating Pressure Mattress System
