StrongBack 24 Ultra-Lightweight Wheelchair

The StrongBack Wheelchair is an ultra-lightweight chair with a innovative posture adjust backrest. Its award winning design represents an evolution of the traditional wheelchair by adding exclusive, frame-integrated posture support while maintaining ease of use and portability. The adjustable back conforms to and supports the natural lumbar curve of the spine and aids in preventing the user from slouching forward and squeezing spinal discs. Decreasing disc pressure results in healthier discs, a stronger back, and long-lasting comfort while seated.

The StrongBack also addresses the challenges of transport with a folding, ultra-lightweight frame, quick release rear wheels, and detachable swing-away footrests.

The StrongBack comes standard with:

+ Swing-Away leg rests
+ Padded desk length arms
+ Anti-tip wheels
+ Wheel-lock
+ Side panel netting – to prevent clothing from getting caught by wheel
+ 300 lb. weight capacity

It is available in three seat widths (16″, 18″ and 20″) and with or without Attendant Handbrakes.

BT ID: 1017 – SB22S, 1017AB – SB22S, 1007 – SB24, 1007AB – SB24, 1010 – SB24, 1010AB – SB24

Seat Width	16", 18", 20"
Attendant Brakes	No, Yes
User Weight	Less than 250 lbs., 251 – 300 lbs.
Weight Capacity	300 lbs

Specifications

Seat Width / Size	16″/Small	18″ / Standard	20″ / Large
Weight Capacity	300 lbs.	300 lbs.	300 lbs.
Total Width	25″	27″	29″
Total Length	43″	43″	43″
Total Height	37″	37″	37″
Length When Folded	28-42″	28-42″	28-42″
Width When Folded	14″	14″	14″
Height When Folded	30″	30″	30″
Total Weight (includes legrests, anti-tippers, wheels, and tools)	29 lbs.	29 lbs.	31 lbs.
Minimum usable weight (includes wheel and excludes tools, legrests, and anti-tippers)	16 lbs.	16 lbs.	17 lbs.
Drive Wheel Diameter	24″	24″	24″
Static Stability	at least 7°
Distance From Footplate to Seat	15-18″
Distance from Armrest to Seat	8″
Seat Angle	12°
Effective Seat Depth	18″
Seat Height at Front Edge	20″
Back Support Height	19″
Back Support Angle	Curved from -10° to +20°
Maximum Obstacle Height	5″
Turning Radius	27″
